From West Room 5, 1st Floor, Building 18, Huilong Yangguang Mingyuan, New District, Xinxiang, Henan, China (Mainland). ■ Specifications
Attention1:
This vertical elevator can be adjusted by customers' specific requirements such as conveying height and steel material.
This vertical elevator can be adjusted by customers' specific requirements such as conveying height and steel material.
Attention2:
The vertical elevator also be called as other name in different country, for example, sometimes will also named it as
Vibrating Spiral Elevator and so on.
Distinctive features:The vertical elevator also be called as other name in different country, for example, sometimes will also named it as
spiral conveyor;
1. Drying and cooling: The elevator can be added drying and cooling device, to make the materials dry and cool.
2. Grading function: This machine can be designed for grading materials accoSrding to different industries and needs, even flammable materials.
3. High conveying efficiency: The shelf backhaul don’t take up working rhythm, and would not be influenced by the conveying height.
4. Multipurpose machine: This elevator can be used for all particles, lumps and powders, only if small viscosity.
Application industries:
The elevator was widely used in mining, metallurgy, machinery, building materials, chemicals, rubber, pharmaceutical, electricity, grain and other industries.
■ Technical Data
|
Type |
Handling capacity(t/h) |
Diameter of groove(mm) |
Conveyor height(m) |
Power(KW) |
Dimension（mm） |
|
DZC300 |
1.0 |
300 |
≤2.0 |
2*0.4 |
680*680*2750 |
|
DZC500 |
2.0 |
500 |
≤3.0 |
2*0.75 |
1080*1080*4020 |
|
DZC550 |
3.0 |
550 |
≤3.5 |
2*1.5 |
1100*1100*4530 |
|
DZC600 |
3.0 |
600 |
≤4.0 |
2*1.5 |
1100*1100*2150 |
|
DZC800 |
4.0 |
800 |
≤4.5 |
2*2.2 |
1300*1300*5650 |
|
DZC850 |
4.0 |
850 |
≤5.0 |
2*2.2 |
1400*1400*6150 |
|
DZC900 |
3.5 |
900 |
≤6.0 |
2*3.0 |
1600*1600*7180 |
